Lathe - cycle-controlled

turning diameter 750-3550 mm mm︱turning length 1000-12000 mm︱control Siemens / Fanuc 0︱total power requirement kW︱weight of the machine ca. t︱required space m︱

---

turning diameter 510 mm︱turning length 1350 mm︱control Style 0︱total power requirement kW︱weight of the machine ca. 2750 t︱required space m︱

---

turning diameter 270 mm︱turning length mm︱control ︱-------------------------------------------------- ︱BASIC FUNCTIONS ︱- design principle: flatbed ︱- number of spindles 1 ︱- number of x/z slides 1 ︱- live positions: yes ︱- number of c-axes 1 ︱WORKING RANGE TURNING ︱- turning diameter (max) 270 mm︱- bar diameter (max) 32 mm︱MAIN SPINDLE ︱- spindle revolutions (max) 5000 /min︱X/Z SLIDE ︱- tool fixture: Turret ︱- tool fixture- turning: VDI 3425 ︱- number of tool positions (total) 8 ︱ELECTRICAL SPECIFICATIONS ︱

---

Machine in TOP condition: Control on : 2200 h Running time : 450 h

turning diameter 450 mm︱turning length 1000 mm︱control FAGOR 8055i ︱centre height 225 mm︱bed width 300 mm︱spindle head DIN 55026/ Gr.6 ︱turning diameter over bed slide 370 ︱turning dia. over face-slide 260 mm︱spindle bore 65 mm︱spindle turning speed - stepless 1 - 3000 U/min︱tail stock ︱pinole diameter 68 mm︱quill stroke 200 mm︱taper in tailstock-quill MK 4 ︱total power requirement 10 kW︱weight of the machine ca. 1,4 t︱dimensions of the machine ca. 2,6 x 1,2 x 1,9 m︱

---

Model ST 225x1000 Manufactured according to DIN 8605 Spindle mount A2 DIN 55026 Feed rates Z, X: 0-7500 mm Standard version: Automatic 8-station tool turret VDI30 machine light, complete machine cover with chip tray instruction book, coolant device, servo spindle motor, automatic lubrication of the guides, Electronic handwheels for X and Z axes, CE compliant Accessories: hydraulic chuck Ø 250 pull cylinder with bore Ø 68 Hydraulic rice stick quill VDI 30 tool disc prepared for part catcher Chip conveyor

turning diameter 1100 mm︱turning length 6000 mm︱control Heidenhain MANUALplus 620︱greates pass round over bed 1120 mm︱Swing diameter over cross slide 820 ︱slide travel facial 600 mm︱max. turning diameter over bed with Multifix/Parat 110 mm︱max. turning diameter over bed with revolver 1000 mm︱spindle diameter in front bearing 190 mm︱spindle bore 132 mm︱spindle taper 140 metr︱main spindle drive at 60% ED 46 kW︱Speed range - up to 1-1800 U/min︱feed range - face slide / stepless 0,001-1000 mm/U︱feed range - longitudinal slide /stepless 0,001-2000 mm/U︱thread pitch min. 0,01 mm︱thread pitch max. 999,9 mm︱rapid travel - longitudinal/face 10/5 m/min︱diameter of quill 125 mm︱quill travel 280 mm︱

---

CNC-Lathe, cycle-controlled, with manual tool carrier - only 490 connected hours Equipment / Accessories: - ZF drive, 2 steps - automatic central lubrication - chip conveyor - 2 pcs. steady rests - various Multifix steel holders - documentation

turning diameter 1100 mm︱turning length 6000 mm︱control Heidenhain MANUALplus ︱total power requirement kW︱weight of the machine ca. 15,1 t︱dimensions of the machine ca. 10,58 x 2,77 x 2,31 m︱

---

CNC-Lathe, cycle-controlled, with ONLY 490 working hours ! Equipment / Accessories: - ZF drive, 2 steps - automatic central lubrication - chip conveyor - 2 pcs. steady rests, max. passage 320 mm + 540 mm - various Multifix steel holders - documentation turning diameter 1100 mm turning length 6000 mm control Heidenhain MANUALplus 620 Max. swing diameter over bed 1120 mm Swing diameter over cross slide 820 mm slide travel facial 600 mm spindle bore 132 mm spindle taper 140 metr main spindle drive (at 60% ED) 46 kW Speed range 1-1800 rpm feed range - face slide / stepless 0,001-1000 mm/r feed range - longitudinal slide /stepless 0,001-2000 mm/r thread pitch min. 0,01 mm thread pitch max. 999,9 mm rapid travel - longitudinal/face 10/5 m/min diameter of quill 125 mm quill travel 280 mm taper MK 6

turning diameter max. 300 mm︱turning length ca. 750 mm︱control Manual plus 620 Heidenhain︱greates pass round over bed 300 mm︱Swing dia. over traverse guideway 150 mm︱Main spindle: ︱turning speed range - main spindle 1 - 4.500 min/-1︱power capacity - main spindel 11,5 / 7,5 kW︱max. Torque ca. 166 Nm︱spindle head DIN 55027 / 5 ︱spindle diameter in front bearing 70 mm︱spindle bore 40 mm︱usable bar diameter 38 mm︱turret: ︱number of toolpositions 8 pos.︱tool taper VDI 20 DIN 69880︱axis stroke: ︱x-axis 170 mm︱z-axis ca. 750 mm︱Tailstock: ︱

---

Lathe - cycle controled SEIGER - SLZ 300 E / 750

turning diameter 800 mm︱turning length 3000 mm︱control SIEMENS 840 D SL ︱swing diameter over slide rest 500 mm︱spindle bore 140 mm︱spindle turning speed range 4 - 1800 U/min︱transmission ratio 2 ︱cross travel (X) 505 mm︱feed range 0 - 6000 mm/min︱tailstock quill diameter 140 mm︱tailstock quill stroke 300 mm︱tailstock quill taper MT 6 ︱main drive 22 / 27 kW︱max. workpiece weight -without tailstock 1000 kg︱max. workpiece weight between centres 4000 kg︱total power requirement kW︱weight of the machine ca. 8,3 t︱dimensions of the machine ca. m︱

---

* Control Siemens 840 D SL with Shop Turn * Automatic programmable change of gearsteps * Visiport in front door * Coolant equipment * Boring bar holder (self-made) for boring bar dia. 80 mm (without boring bar) * Heavy duty boring bar holder, for boring bar dia. 120 mm (without boring bar) * 3-jaw power-chuck FORKARDT 3FNC 630-125 * Steady-rest, make RICHTER, type 5-1, center height 400 mm, clamping range 500 - 20 mm, max. workpiece weight 5.000 kg * PARAT 4-station toolholder size 4 with internal coolant * Chip conveyor, built 2016 * Portable handwheel * Oilmist-extractor * Tailstock with quill dia. 140 mm and with built-in rotating MT5 taper * High pressure pump for coolant (1,7 kW; Max p=9,0 bar; Max Q= 64 l/min; 20 l/min at 6,3 bar; 30 l/min at 5,0 bar; 40 l/min at 3,5 bar) Machine will be sold without tools.

turning diameter 370 mm︱turning length 3000 mm︱center height over bed 630 mm︱swing diameter over face slide 370 mm︱spindle bore 105 mm︱spindle speeds: 2 Stufen 2 - 2500 U/min︱tool taper REVOLVER VDI 40 ︱control Siemens 810D MANUAL TURN︱total power requirement 18,5 kW︱weight of the machine ca. 5 t︱

---

Equipment: swarf protector automatic cooling device RS 232 interface 3-jaw chuck diameter 315mm automatic lubrication system Part-Documentation LUNNETTE +TURRET 12 POSISITION VDI 40

turning diameter 650 mm︱turning length 3.000 mm︱control HEIDENHAIN MANUALplus ︱total power requirement 33 kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

Lathe - cycle controled / Brand: KERN-DMT / Type: CD 650 Year of construction: 2010 The machine can be inspected by appointment under working condition. Very good, operational condition (regularly serviced). Spindle hours (02/02/2021): 5.738 h TECHNICAL SPECIFICATIONS: - Control: Heidenhain MANUALplus 620 Working area: - Swing diameter over bed: 650 mm - Swing diameter over cross slide: 420 mm - Sleigh path plan: 440 mm - Turning length: 3.000 mm Horizontal bed: - Prismatic flat track guide hardened and grinded Main spindle drive: - Digital AC motor - 40% ED: 33 kW Gearbox: - ZF planetary gearbox, 2 steps - electrically switched - mounted outside the headstock Spindle cabinet: - Spindle head: Size A8, DIN 55026 - Spindle diameter in the front bearing: 140 mm - Spindle bore: 106 mm - Speed range: 1 - 2.500 rpm Cross slide: - Feed range plan: 0,001 - 1.000 mm/U - Feed range longitudinal and thread pitches: 0,001 - 2.000 mm/U - Thread pitches: 0,01 - 999,9 mm - Rapid traverse plan/ longitudinal: 5/10 m/min - Automatic central lubrication - Digital AC servo motors plan and longitudinal Tailstock: - Pinole diameter: 100 mm - Pinole path: 200 mm - Acquisition cone: 5 Mk - Eccentric clamping and additional clamping screw - Manual spindle sleeve actuation and clamping - Tailstock roller guide Electrical equipment: - Three-phase current: 400 V, 50 Hz Extensive equipment, accessories. - Documentation - CE marking There is no guarantee for correctness and completeness of the technical details and accessories. Detailed technical data sheet and information on equipment available on request.

turning diameter 430 mm︱turning length 1000 mm︱control SIEMENS 840D Sol.Line ︱swing diameter over slide rest 225 mm︱centre distance 1150 mm︱spindle turning speed range -3600 U/min︱turret head 8 Pos. ︱weight of the machine ca. 3.6 t︱dimensions of the machine ca. 4x2x2 m︱

---

Misc.accessories More details on www.marcels-maschinen.ch

turning diameter 570 mm︱turning length 2000 mm︱control Siemens ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

Siemens control 3-jaw chuck Multifix tool holder device steady rest tail stock coolant device Technische Daten / technical details: max. Drehlänge / max. turning lenght 2000 mm Umlauf-Ø über Bett / turning Ø over bed 570 mm Umlauf-Ø über Schlitten / turning Ø over sledge 340 mm Drehzahlbereich / spindle speed 1-2500 UpM /rpm Spindelbohrung / spindle hole 83 mm Reitstockaufnahme / tail stock taper MK5 Antriebsleistung / drive capacity 30 kW Gewicht der Maschine / weight 3200 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

greates pass round over bed 540 mm︱turn - diameter over facing slide 310 mm︱centre distance 1500 mm︱centre height 270 mm︱control SIEMENS 810 D ︱turning speed range 2250 U/min︱spindle nose A2 -11 ︱spindle bore 85 mm︱spindle taper 6 MK︱travel of carriage X/Z-axis 300/1550 mm︱feed X/Z-axis 5000 mm/min.︱rapid traverse 8000 mm/min.︱tailstock quill taper MT 5 ︱quill stroke 210 mm︱pinole diameter 75 mm︱total power requirement 12,5 kW︱weight of the machine ca. 3.7 t︱dimensions of the machine ca. 3,00 x 1,85 x 1,90 m︱

---

acc.: 3-jaw chuck 200 mmØ, MULTIFIX-toolpost with various inserts, solid steady, running centre, coolant

turning diameter - mm︱turning length - mm︱control SINUMERIK 840 D ︱swing over bed 1.000 mm︱swing diameter over face slide 650 mm︱Distance between centres 4.000 mm︱movement cross slide 680 mm︱bed width 750 mm︱lathe tool cross section h x w 40 x 40 mm︱main spindle : ︱spindle diameter in front bearing 360 mm︱spindle bore 200 mm︱power 60/100% ED 52/37 kW︱max. torque on the spindle 6.000 ︱turning speed range 3,55-910 U/min︱feed power X 100% ED 20.000 N︱feed power Z 100% ED 30.000 N︱rapid traverse X-axis 3 m/min︱rapid traverse Z-axis 6 m/min︱diameter of quill 160 mm︱

---

accessories - full cover closed at the top - preparation for extraction system - 4-fold tool turret manufacturer SAUTER - boring bar holder mounted on cross slide - hydraulical clampable tailstock - 2 piece steady‘s, Ø 80 – 450 + Ø 440 – 800 mm - 2 piece chip conveyor longitudinal – ejection right - workroom doors automatically operated - power chuck equipment without chuck - coolant equipment with paper band filter - control SINUMERIK 840 D incl. roughing - Machine will be delivered without chuck

turning diameter 360 mm︱turning length 820 mm︱control Heidenhain MANUALplus 4110︱travel -z axis 890 mm︱swing diameter over flat guideway 475 mm︱swing diameter over face slide 260 mm︱cross movement 260 mm︱main drive motor 22/19,5/17 kW︱transmission ratio 2 ︱spindle turning speed range 1 - 3000 U/min︱spindle diameter in front bearing 110 mm︱rapid travel - longitudinal/face 10/5 m/min︱power feed longitudinal 9000 N︱power feed coss 6000 N︱tailstock quill taper MT 5 ︱tailstock quill diameter 70 mm︱tailstock quill stroke 120 mm︱total power requirement kW︱weight of the machine ca. 2,9 t︱dimensions of the machine ca. 4150 x 2825 x 1700 mm︱

---

Equipped with: Control Heidenhain MANUALplus 4110 Toolholder and boring holder Chip conveyor Hydraulic unit for power-chuck Documentation Without chuck.

turning diameter 554 mm︱turning length 1000 mm︱control FANUC 21 ITB ︱centre height 280 mm︱swing diameter over face slide 370 mm︱swing in the gap 830 mm︱spindle bore 90 mm︱spindle turning speed range 15 - 1800 U/min︱spindle nose D 1 - 8" Camlock ︱spindle drive 11 kW︱feeds - longitudinal 0,03 - 0,4 mm/U︱feeds - cross 0,015 - 0,2 mm/U︱rapid travel - longitudinal/face 3 / 1,5 m/min︱thread - mm pitch 14 mm︱bed width 400 mm︱radial face slide travel 310 mm︱tailstock quill diameter 95 mm︱tailstock quill stroke 145 mm︱tailstock taper MT 6 ︱tailstock adjustment out of the central pos. +/- 10 mm︱

---

CNC FANUC 21 ITB Acc.: 3-jaw chuck 315 mmø,ROEHM DURO NC HYDRAULIC TURRET 8 POSITIONS VDI 40 various inserts, 1 solid steady,+ 1 MOVING STEADY coolant CHIP CONVOYER

centre height 550 mm︱centre distance 2000 mm︱turning diameter over bed 1100 mm︱turning diameter over slide 790 mm︱turning length 2000 mm︱spindle taper D1-11 ︱control Sinumerik 810D Shopturn ︱bed width 622 mm︱spindle bore 140 mm︱turning speed range 4-300 / 160 - 1200 U/min︱feed: 0 - 6000 mm/min︱rapid travel - longitudinal/face 6 / 6 m/min︱powered chuck diameter 630 mm︱hollow clamping cylinder dia. 117,5 mm︱tool turret 8 Pos. Sauter︱drive capacity - spindle motor 37 kW︱taper in tailstock-quill MK 6 ︱dia. of quill 140 mm︱quill stroke 220 + 80 mm︱coolant ︱

---

Machine has life tools and spindle indexation 2,5° - Serial No.: 060559 - hydr. 3-Jaw power chuck Kitagawa dia.630 mm - hydr. quill on tail stock - indexing spindle every 2,5° - 8 Pos. tool turret for life tools (Sauter) Machine is being reconditioned at present. It will be ready for sale at approx. June 2020 Price subject to change until final completion of the reconditioning work.

turning diameter 500 mm︱turning length 850 mm︱control DRO ︱greates pass round over bed 500 mm︱swing diameter over slide rest 250 mm︱chucking diameter 250 mm︱cross movement 260 mm︱drive capacity - workpiece 12 kW︱reus 10-3000 U/min︱transmission ratio 2 ︱weight of the machine ca. 2,7 t︱dimensions of the machine ca. 2,90x1,95x1,82 m︱

---

centre height 215 mm︱centre distance 1.000 mm︱turning diameter over bed 430 mm︱turning diameter over slide 200 mm︱spindle bore Ø 53 mm︱spindle taper KK 5 DIN 55026︱3-jaw-chuck diameter 250 mm︱control Sinumerik 810 D SIEMENS︱bed width 305 mm︱turning speed range 3 - 4.000 U/min︱turret head 8 Pos.︱travel -x axis 220 mm︱travel -z axis 1.000 mm︱rapid travel - longitudinal/face 10 / 7,5 m/min︱drive capacity - spindle motor 12,5 kW︱taper in tailstock-quill MK 4 ︱dia. of quill 60 mm︱quill stroke 120 mm︱voltage 400 V︱total power requirement 15,0 kVA︱

---

- Serial-No.: 002-090273-403 - control: SIEMENS Sinumerik 828 D - Tool turret DUPLOMATIC - 3-jaw-self-centering wedge bar Chuck SCHUNK - chip conveyor - fixed Steady

turning diameter 280 mm︱turning length 500 mm︱control Heidenhain 4110︱centre distance 500 mm︱greates pass round over bed 280 mm︱swing diameter over slide rest 140 mm︱spindle bore 45 mm︱drive capacity - spindle motor 11,5 kW︱turning speeds 1-5000 U/min︱rapid traverse X-axis 13 m/min︱rapid traverse Z-axis 7 m/min︱tailstock quill 50 mm︱quill stroke 120 mm︱taper MK 3 Mk︱spindle head 55027 Gr. 5 ︱weight 1,6 t︱Mechanic: very good ︱Optical condition: very good ︱The machine can be viewed under current. ︱

---

# 23C1.04 * Color: light gray RAL 7035 / brilliant blue RAL 5007 * Control Heidenhain Manual-Plus 4110 * Control panel can be moved to the left and right * Switch-on hours counter 9600 h * Sauter disc turret 8-fold * Main spindle in C-axis design * 4 powered stations * 22 VDI 20 holders * 2 driven tools * Röhm DURO S three-jaw wedge bar chuck: Ø 160 mm * Quick chuck facility * 9 collets * 4-way parat holder * 4 inserts * Hollow spindle stop * revolving center point new * solid center point * Tailstock roller guided for easier movement * 2 NC precision drill chucks * Reducing sleeves * Machine light * 6 machine shoes * Central lubrication pump * Chip tray * Coolant facility * Operation manual * Operating manual * Electric wiring diagram Machine is currently being checked in the workshop with an electrical one Acceptance protocol, turning test and declaration of conformity delivered! The pictures are from our archive of a sold machine, as soon as it comes out of the workshop we will insert original pictures.

turning diameter 248 mm︱turning length 400 mm︱control HEIDENHAIN ︱centre distance 500 mm︱spindle turning speed range -6000 U/min︱weight of the machine ca. 1.3 t︱

---

Misc accessories www.marcels-maschinen.ch

centre height 195 mm︱centre distance 1250 mm︱turning diameter over bed 400 mm︱turning diameter over slide 245 mm︱turning dia. in gap 585 mm︱turning length 1250 mm︱spindle taper CAMLOCK KK 6 DIN 55029︱control FANUC ︱bed width 320 mm︱spindle bore 55 mm︱turning speed range 15 - 2500 U/min︱rapid travel - longitudinal/face 4 / 3 m/min︱quick change toolholder PARAT ︱drive capacity - spindle motor 7,7 kW︱taper in tailstock-quill MK 5 ︱dia. of quill 75 mm︱quill stroke 150 mm︱coolant ︱voltage 400 V︱total power requirement 11,0 kW︱

---

- Serial-No.: D3D040/17 - control: FANUC - with live steady - fixed steady - 4-jaw chuck Ø 250 mm - coolant equipment

turning diameter 500 mm︱turning length 1000 mm︱control Monforts MTC K CNC︱turning diameter over slide 290 mm︱spindle passage 70 mm︱turning speed range 2 - 2800 U/min︱spindle motor 15 kW︱tailstock quill diameter 80 mm︱tailstock quill stroke 160 mm︱tailstock taper MT 5 ︱total power requirement kW︱weight of the machine ca. 5 t︱dimensions of the machine ca. 3000 x 1800 x 1700 mm︱Control ︱

---

turning diameter 1250 mm︱turning length 5000 mm︱control FAGOR 8055 TC ︱centre height 625 mm︱centre distance 5000 mm︱turning diameter over slide 940 mm︱spindle bore 128 mm︱spindle turning speed range 2 - 800 U/min︱spindle motor 37 kW︱feeds - longitudinal 1 - 1000 mm/min︱feeds - cross 1 - 1000 mm/min︱rapid travel - longitudinal/face 5 m/min︱max. workpiece weight between centres 6000 kg︱workpiece weight in steadies max. 8000 kg︱tailstock quill diameter 150 mm︱tailstock quill stroke 200 mm︱taper in tailstock MT 6 ︱tailstock adjustment out of the central pos. +/- 10 mm︱bed width 800 mm︱bed height 630 mm︱

---

- CNC control FAGOR 8055 TC - Face plate 800 mmø, - Steel holder Parat RD 5 - steady rest 160-420 mm - Coolant unit - Tailstock motor adjustable - Chip conveyor
